Milk Production Line Dust collecting Machine / Dust Extractor
Reference parameter:
1. Elegant & splendid : Whole machine are made from full stainless steel including draught fan, it is accord with working environment of food grade.
2. High efficiency : The singlde drum filter of folding micron grade can absort more powders.
3. Strong strength : Secial design of multi blade wind wheel with more stronger suction abiblity.
4. Convenient cleaning : One-key type vibraion cleaning powders, be more efficient to romove the powders which attached the cylindar filter, clean dusts efficiently.
5. Hommization : Adding romote controlling system, be convenient to distance controlling equipments.
6. Lower noises : Special insulation cotton reduce noises more efficiently.
It is especially suitable for pharmaceutical, mik powder filling production line and other powder processing.
More picture to show:
Our exhibition:
Reference parameter:
| Model no. | Blowing rate(m3/h) | Pressure(pa) | Power(kw) | Equipment max noise(Db) | Dimension(mm) | Weight (kg) |
| TDCC-1.5A | 750-1050 | 940-690 | 1.62 | 60 | 680x600x1610 | 152 |
| TDCC-2.2A | 1350-1650 | 960-580 | 2.32 | 65 | 710x640x1740 | 190 |
| TDCC-3.0A | 1700-2400 | 1680-1100 | 3.12 | 70 | 770x670x1810 | 235 |
| TDCC-4.0A | 2650-3500 | 1680-1100 | 4.12 | 70 | 830X680X1880 | 290 |
| TDCC-5.5A | 3800-4500 | 1680-1100 | 5.62 | 75 | 910X760X1970 | 350 |
| TDCC-7.5A | 4800-7000 | 1680-1100 | 7.62 | 75 | 960X800X2020 | 420 |
| Please feel free to contact us if you need more technical parameters ! | ||||||
FAQ:
1. Manufacturer or trading company : Manufacturer
2. Location : Songjiang district , Shanghai
3. Selling markets: Euope , American , Australia , Asia , Africa
4. Customized: Available for customized designs
5. Delivery time: 15 - 30days
6. Warranty period: 1 year
Main future of dust collector:1. Elegant & splendid : Whole machine are made from full stainless steel including draught fan, it is accord with working environment of food grade.
2. High efficiency : The singlde drum filter of folding micron grade can absort more powders.
3. Strong strength : Secial design of multi blade wind wheel with more stronger suction abiblity.
4. Convenient cleaning : One-key type vibraion cleaning powders, be more efficient to romove the powders which attached the cylindar filter, clean dusts efficiently.
5. Hommization : Adding romote controlling system, be convenient to distance controlling equipments.
6. Lower noises : Special insulation cotton reduce noises more efficiently.
It is especially suitable for pharmaceutical, mik powder filling production line and other powder processing.
