Product Description:
Application:
Liquid: detergent, fruit juice, miller wine, soy sauce, vinegar, drinks, etc
Thick Liquid: chilli sauce, ketchup, peanut butter, jam, bean sauce, etc
Features and Characteristics:
1. The Liquid, paste packaging system consists of a rotary packing machine and a liquid or paste filling machine
2. A perfect quality ensures a speedy and stable production
3. High quality accessories make machines durable and stable
4. Waterproof system makes cleaning easier. Color touch screen display, easy to operate
5. The machine and the other devices make up a packaging system
6. Provide an innovative and practical solution at reasonable costs
7. A low material waste. The machine adopts premade perfect-pattern pouch, with high-quality sealing
Pouch Type:
Work Process:
Standard Equipment Part:
Optional Configuration:
Material weighing&filling machines, working platform, check weigher, material elevator, finished product conveyor, metal detector
| Model | MR8-200CY |
| Working Positions | Eight Positions |
| Pouch Type | Four-side Sealed Bags, stand-up pouches, zipper bags, three-side sealed bags, paper bags, etc. |
| Capacity | 20-40 bags/min(speed may vary with product charcateristics, pouch or other operation condition) |
| Bag Size | Width:80~210mm Length:100~300mm |
| Filling Volume | 10-1500g(Depend on type of products) |
| Package Error | ≤±1 |
| Dimension | 1450*1560*1525mm(L*W*H) |
| Weight | 1450KGS |
| Compress air requirement | ≥0.8m³/min supply by user |
Application:
Liquid: detergent, fruit juice, miller wine, soy sauce, vinegar, drinks, etc
Thick Liquid: chilli sauce, ketchup, peanut butter, jam, bean sauce, etc
Features and Characteristics:
1. The Liquid, paste packaging system consists of a rotary packing machine and a liquid or paste filling machine
2. A perfect quality ensures a speedy and stable production
3. High quality accessories make machines durable and stable
4. Waterproof system makes cleaning easier. Color touch screen display, easy to operate
5. The machine and the other devices make up a packaging system
6. Provide an innovative and practical solution at reasonable costs
7. A low material waste. The machine adopts premade perfect-pattern pouch, with high-quality sealing
Pouch Type:
Work Process:
Standard Equipment Part:
| 1. Date printer | 6. Magnetic valve |
| 2. PLC control system | 7. Temperature controller |
| 3. Pouch opening devices | 8. Vacuum pump |
| 4. Vibrator device | 9. Frequency convertor |
| 5. Cylinder | 10. Output system |
Optional Configuration:
Material weighing&filling machines, working platform, check weigher, material elevator, finished product conveyor, metal detector
